Tinned coppersolar cable DC 1.5KV AC 0.6/1KV single core cable 185mm2 H1Z2Z2-K TUV Certification

Name: Tinned coppersolar cable DC 15KV AC 061KV single core cable 185mm2 H1Z2Z2K TUV Certification
Brand: Zhenglan Cable
Price: 1 USD

China Tinned coppersolar cable DC 1.5KV AC 0.6/1KV single core cable 185mm2 H1Z2Z2-K TUV Certification wholesale

Brand Name : Zhenglan Cable

Model Number : solar cable 185mm2

Certification : 3C，ISO 9001:2015，ISO 14001:2005

Place of Origin : China

MOQ : 5000meters single color

Price : Negotiable

Payment Terms : T/T,L/C,,Western Union

Supply Ability : 80000M/DAY

Delivery Time : 7-15DAY

Packaging Details : 1000m/drum

Material : Tinned Copper

Insulation : cross linkedin polyolefin

Outer sheath : cross linkedin polyolefin

Size : 185mm2

Standard : EN50618, EN50332-1

Voltage : DC 1.5KV

Contact Now

Application:

DC Cable H1Z2Z2-K acc. to EN 50618, are intended for use in Photovoltaic Power Supply Systems at nominal voltage rate up to 1,5/1,5kV DC.They are suitable for applications indoor and/or outdoor, in industrial and agriculture fields, in/at equipment with protective insulation (Protecting Class II), in explosion hazard areas.They may be installed fixed, freely suspended or free movable, in cable trays,conduits, on and in walls.DC Cable H1Z2Z2-K are suitable for direct burial where the corresponding guidelines for direct burial shall be considered

Dimension characteristics:

Rated Voltage	D.C. 1.5/1.5 kV A.C. 1.0/1.0 kV
Max. permissible operating voltage AC	1.2/1.2 kV
Max. permissible operating voltage DC	1.8/1.8 kV
Nominal Cross Sectional	185mm²
Number of wires in conductor	925
Diameter of wires in conductor	0.50mm
Tolerance of wires in conductor	±0.005 mm
Mean Thickness of Insulation	1.60 mm
Mean Thickness of Sheath	1.60 mm
Max. Mean Overall Diameter	28.50 mm
Approx. Cable Weight	1983.20 kg/km
Conductor D.C resistance at 20°C	0.108 Ω/km
